160r pvc blister packaging machine is a machine suitable for pharmacy. It is a package of tablets, capsules, soft capsules, electronic cigarettes, candy, etc. It can use PVC/PET/PS, aluminum-plastic, aluminum-aluminum, paper-plastic and other materials, with a variety of materials, giving you more options for packaging.
160r pvc blister packaging machine is one of our company's main machines.
Firstly because of its wide range of materials and low operating costs, and secondly because of its high cost performance.
It has a new type of servo motor roller traction, an integrated floor-standing box seat, a large platform design, a mold drawing card slot design, automatic alarm when the fragment is stopped, photoelectric detection of punching, a safety cover at the workstation, and a PVC the feeding motor.
The heat-sealing station has the characteristics of dual-cylinder and dual-axis linkage, a new type of helical gear reducer motor, chain drive, fixed four columns at the station, emergency stop device, and blister machine with waste recycling.
The above characteristics are enough to prove the 160r's high cost performance, and give your packaging more peace of mind and guarantee.
Model | DPP 160R pvc blister packaging machine |
Number of blanking | 20~50 times/ min |
Production Capacity | 1200-4200 plates/ h |
Maximum forming area and the Max. depth | 130*100*15mm Max. Depth 26mm(the machine can custom made) |
Standard Travel Range | 40~110 mm |
Standard Plate | 80*57 mm |
Power of Main Motor | 1.5kW |
Mold Cooling | Runing water or circulating water |
Weight | Net weight 1600 kg ; |
